Posted : admin On 01.01.2020. Loader Dimensional Specifications.
(A) Max. Lift height to bucket pivot pin. Standard 71.3 in. (1810 mm). (B) Max. Lift height under level bucket.
Standard 66.1 in. (1680 mm).
(C) Clearance with bucket dumped. Standard 52.4 in. (1330 mm). (D) Reach at max. Lift height. Standard 28.9 in.
(735 mm). (E) Max. Dump angle. Standard 45º.
(F) Reach with bucket on ground. Standard 54.7 in. (1390 mm). (G) Bucket roll-back angle. Standard 29º. (H) Digging depth.
Standard 4.7 in. (120 mm). (J) Overall height in carrying position 39.0 in.
Loader Operational Specifications. Lift Capacity (Bucket bottom mid point). Standard 529 lbs. (240 kg). (U) Lift Capacity (Bucket pivot pin, max height). Standard 750 lbs (340 kg).
(V) Lift Capacity (500 mm forward, max height. Standard 518 lbs. (235 kg).
(W) Lift Capacity (Bucket pivot pin, 1.5 M height). Standard 827 lbs. (375 kg). (X) Lift Capacity (500 mm forward, 1500 mm height). Standard 595 lbs.
Cat 416 Backhoe Manual
(270 kg). (Y) Breakout Force (Bucket pivot pin). Standard 1415 lbs. (6290 N). (Z) Breakout Force (500 mm forward). Standard 992 lbs. (4410 N).
(VV) Bucket roll-back force at max. Height. Standard 1069 lbs. (4750 N). (XX) Bucket roll-back force at 1.5 M. Standard 1260 lbs. (5600 N).
(ZZ) Bucket roll-back force at ground level. Standard 1235 lbs. (5490 N). Raising time 3.5 sec.
Case Backhoe Manual
Jd 310 Backhoe Manual
Lowering time 2.7 sec. Bucket dumping time 1.7 sec. Bucket roll-back time 2.4 sec.
