Bogen models TPU35B, TPU60B, TPU100B, and TPU250 are wall-mounted telephone paging amplifiers rated at 35, 60, 100, and 250 watts, respectively. All models can also be rack-mounted. These TPU amplifiers permit paging from telephone and/or microphone; music input through an RCA jack or screw terminals; and voice-activated, variable level, music mute with fade back after page. These TPU amps include a night ringer which sends an electronic ringing tone signal through all speakers, alerting personnel of incoming calls. Jacks are also provided to bridge two TPU amplifiers to double the number of inputs and output power. BUY Direct and SAVE! At Telcom & Data we strive for long term customer relationships, that' why we offer a 60 day 100% money back guarantee on ALL of our products.

Bogen Paging System Manual

(Except Special Made-to-Order Products, including Wheelock MEDC and Explosion Proof Products) If you are not happy with a product for any reason simply call us at 800-335-0229 and request a Return Authorization number for a full 100% credit. All returns require prior authorization, please. Returned items must be repacked in ORIGINAL packaging NO EXCEPTIONS.

Telcom & Data wants to be your one stop telecommunications company. Let us know how were doing by calling 800-335-0229 and ask for extension 832.

. Telephone Paging Amplifier Models TPU35B, TPU60B, TPU100B, TPU250 Installation and Use Manual © 2005 Bogen Communications, Inc. All rights reserved.

Specifications subject to change without notice. 54-5900-01D 1101. NOTICE: Every effort was made to ensure that the information in this guide was complete and accurate at the time of printing.

Data Files for Students. Guide to TCP/IP, 4th Edition. Carrell, Laura Chappell, Ed Tittel, James Pyles ISBN-10:. ISBN-13: 862. Guide to tcp/ip 4th edition answers. With Chegg Study, you get step-by-step solutions to the odd and even problems in 9,000+ textbooks. Laura Chappell, Ed Tittel, Jeffrey L Carrell, James Pyles. Get unlimited access to Textbook Solutions for more than 9,000 textbooks. Access TCP/IP Protocol Suite 4th Edition solutions now. Our solutions are written by Chegg experts so you can be assured of the highest quality! Guide to TCP IP 4th Edition Carrell Solutions Manual - Test bank, Solutions manual, exam bank, quiz bank, answer key for textbook download instantly!

Bogen Tpu60b Paging Amplifier Manual

However, information is subject to change. WARNING: To reduce the risk of Fire or Electric Shock, Do Not Expose this apparatus to rain or moisture. Contents INTRODUCTION.4 PACKAGE CONTENTS.4 INSTALLATION.5 Mounting Ventilation Wall Mounting Rack Mounting the TPU35B, TPU60B, & TPU100B Rack Mounting the TPU250 INPUT WIRING CONNECTIONS.6-7 Music Input Microphone Input TEL Input Night Ringer Connection Bridging Inputs Input Cover Replacement OUTPUT WIRING CONNECTIONS.8 Speaker Connection Line-Matching Transformer WMT1A Connector. Figure 1a: TPU250 Telephone Paging Amplifier Telephone Paging Amplifier Introduction This document describes the Bogen TPU35B, TPU60B, TPU100B (See Fig.1) and TPU250 (see Fig.1A) Telephone Paging Amplifiers. They are full-featured, wall-mounted amplifiers that provide inputs for dry-loop, 600-ohm telephone page signal, background music source, and low impedance microphone. Installation Figure 3: Rack Mounting the TPU250.

Figure 2: Wall Mounting the Amplifier See NOTE below for information on alternate orientation. Screw #8 x 5/8” (M4 x 16mm) with Screw #8 x 5/8 “ (M4 x 16 mm) with Rack Mounting Screws Synthetic washer 1/8”. The music input is a mono unbalanced input, so the music sourceʼs output should be unbalanced and mono. If a balanced input is needed, use a Bogen Line-Matching Transformer WMT1A (sold separately) to balance the music input. The WMT1A is also effective in breaking ground loops that cause hum. Input Wiring Connections Night Ringer Connection Either a standard telephone (analog) ring signal (90 – 105V AC, 20 – 30 Hz) or an external contact closure activates the night ringer function of the amplifier.

To activate the night ringer using standard telephone (analog) ring, connect the analog station's tip lead to the TEL RING 'T'. Output Wiring Connections All output wiring connections are made to the terminal strip located under the right side access panel. Loosen the two Phillips-head screws on each side of the cover and remove the cover. IMPORTANT: Before making any connections or wiring changes to the amplifier or any equipment connected to the amplifier, make sure that the amplifier is NOT plugged into an AC outlet. Operation Indicator LEDs The POWER LED illuminates whenever AC power is applied to the amplifier (there is no power switch on the amplifier). POWER The PEAK LEVEL LED illuminates whenever the speaker output signal level approaches its maximum level. This indicator is used when setting PEAK LEVEL volume levels.

Operation RINGER VOLUME adjusts the level of the night ringer tone output. The RINGER VOLUME music volume level should first be set to the customer's satisfaction. When adjusting this level, the PEAK LEVEL indicator should be used to ensure that the amplifier signal is not distorted. MUSIC MUTE adjusts the level of the background music heard during a MUSIC MUTE paging announcement. Specifications Technical Specifications Power Output: TPU35B: 35W RMS; TPU60B: 60W RMS; TPU100B: 100W RMS; TPU250: 250W RMS Frequency Response: 70 Hz to 15k Hz ±1 dB Distortion: Less than 1% Hum & Noise: (20 Hz to 20 kHz) MUSIC: -70 dB; TEL: -70 dB; MIC: -55 dB Sensitivity: MUSIC: 85mV. State to State. Products that are out of warranty will also be repaired by the Bogen Factory Service Department – same address as above or call 201-934-8500.
